Tripp Lite PDU Metered 200-240V 20A 8 C13; 2 C19 Outlet L6-20P 1U RM TAA
Tripp Lite PDU Metered 200-240V 20A 8 C13; 2 C19 Outlet L6-20P 1U RM TAA - 1UHorizontal Rackmount
| $371.49 |
- Metered single phase 16/20A 200-240V PDU
- 1U horizontal rackmount; Digital current meter
- C20 input with L6-20P plug adapter; 12 ft. / 3.7m line cord
- 10 total outlets (8 C13, 2 C19)
Manufacturer:
Tripp Lite by Eaton
Item:
PDUMH20HV
UPC Code:
037332159014
Our Part #
TRPPDUMH20HV
Condition
New
$371.49EA
Availability
Currently out of stock
You may be also interested
Product description
Tripp Lite PDU Metered 200-240V 20A 8 C13; 2 C19 Outlet L6-20P 1U RM TAA - 1UHorizontal Rackmount
1UHorizontal Rackmount
Specifications
Brand Name
Tripp Lite
Country of origin
Taiwan
Depth
6.5"
Environmental Certification
RoHS
Environmentally Friendly
Yes
Height
1.8"
Input voltage
230 V AC
Input Voltage Range
200 V AC - 240 V AC
Limited Warranty
2 Year
Manufacturer
Tripp Lite by Eaton
Manufacturer Part Number
PDUMH20HV
Manufacturer Website Address
http://www.tripplite.com
Marketing Information
PDUMH20HV Metered 1U rack PDU supports 20A maximum capacity at 208/240 & 230V (agency de-rated to 16 amps). Includes C20 inlet and detachable input cable with both C20 and L6-20P input plug options. 10 total output receptacles (8 C13 and 2 C19). Visual current meter tracks the output current of all outlets combined. Supports 1U rackmount installation in 19 inch 2 or 4 post racks. Included cord retention bracket keeps vital network equipment plugged in and continuously powered.
Mount Type
Rack-mountable
Mounting Orientation
Horizontal
Mounting Orientation
Horizontal
Mounting Orientation
Horizontal
Output Voltage
208 V AC
Output Voltage
240 V AC
Package Contents
- Metered PDUMH20HV 10-Outlets PDU
- Rackmount Brackets
- Cord Retention Brackets
Plug/Connector Type
NEMA L6-20P
Plug/Connector Type
IEC 60320 C20
Product Name
Metered PDUMH20HV 10-Outlets PDU
Product Series
Metered
Product Type
PDU
Protection Type
Overload Protection
Rack Height
1U
Receptacle Detail
2 x IEC 60320 C19
Receptacle Detail
2 x IEC 60320 C19
Receptacle Detail
8 x IEC 60320 C13
Receptacle Detail
8 x IEC 60320 C13
Receptacle Type
IEC 60320 C13
Receptacle Type
IEC 60320 C19
UPC Alternates
037332159014 803930103342 818242945467 974573824984 993246979592
Weight (Approximate)
6.80 lb
Width
17.5"
